Waveshare Open429I-C Standard, STM32F4 Development Board

STM32 development board designed for STM32F429I, features the STM32F429IGT6 MCU, and integrates various standard interfaces, pretty easy for peripheral expansions.Overview1. Open429I-C is an STM32 development board designed for the STM32F429IGT6 microcontroller, consists of the mother board and the MCU core board Core429I.2. The Open429I-C supports further expansion with various optional accessory boards for specific application. The modular and open design makes it the ideal for starting application development with STM32 series microcontrollers.What has on the mother board1. MCU core board connector: for easily connecting the Core429I2. USART3 interface: easily connects to RS232, RS485, USB TO 232, etc.3. DCMI interface: for connecting camera4. Capacitive touch panel interface: for connecting capacitive touch panel5. CAN2 interface: for connecting CAN modules6. CAN1 interface: for connecting CAN modules7. SDIO interface: for connecting Micro SD module, features much faster access speed rather than SPI8. ULPI interface: for connecting high-speed USB peripheral (the STM32F429I integrates USB HS controller without any PHY device)9. LCD interface 1: for connecting 7inch LCD10. ONE-WIRE interface: easily connects to ONE-WIRE devices (TO-92 package), such as temperature sensor (DS18B20), electronic registration number (DS2401), etc.11. LCD interface 2: for connecting 4.3inch LCD12. I2C2/I2C3 interface: easily connects to I2C peripherals such as I/O expander (PCF8574), EEPROM (AT24Cxx), etc.13. SAI1 interface: for connecting audio modules like UDA1380 module14. Ethernet interface: for connecting Ethernet modules15. USB connector: USB to UART via the onboard convertor PL230316. SPI1/SPI2 interfaces:- Easily connects to SPI peripherals such as DataFlash (AT45DBxx), SD card, MP3 module, etc.- Easily connects to AD/DA modules (SPI1 features AD/DA alternative function)17. I2S2/I2S3/I2C1 interface: easily connects to I2S peripherals such as audio module, etc.18. 8-bit FMC interface: easily connects to peripherals such as NandFlash19. 5V DC jack20. 5V/3.3V power input/output: usually used as power output, also common-grounding with other user board21. MCU pins connector: all the MCU I/O ports are accessible on expansion connectors for further expansion22. PL2303: USB to UART convertor23. LEDs: convenient for indicating I/O status and/or program running state24. PL2303 TX-LED / RX-LED25. 12MHz crystal: for PL230326. Joystick: five positions27. WAKE UP button: used as regular button, and/or wake up the STM32 MCU from sleep28. USB to UART jumper29. LED jumper- Short the jumper to connect to default I/Os used in example code- Open the jumper to connect to custom I/Os via jumper wires30. Button/Joystick jumper- Short the jumper to connect to default I/Os used in example code- Open the jumper to connect to custom I/Os via jumper wiresPackage Contains1. Open429I-C development board x 12. USB type A plug to mini-B plug cable x 13. USB type A receptacle to mini-B plug cable x 14. 4-pin 2-pin wires pack x 15. USB power cable x 16. Software CD x 1
