ELM327WIFI V1.5 OBD2 Car Fault Diagnostic Tool PIC18F25K80 Chip

• Product type: Code Readers & Scan Tools
• Compatibility: OBD-II compliant vehicles
• Material: Not specified
• Key feature: Reads and clears diagnostic trouble codes
• Color/Variant: Not specified
• Intended use: Everyday use
• Category: Diagnostic Scan Tools

Functions1. Read diagnostic trouble codes, both generic and manufacturer-specific, and display their meaning (over 3000 generic code definitions in the database). 2. Clear trouble codes and turn off the MIL 3. Display current sensor data, including: 4. Engine RPM 5. Calculated Load Value 6. Coolant Temperature 7. Fuel System Status 8. Vehicle Speed 9. Short Term Fuel Trim 10. Long Term Fuel Trim 11. Intake Manifold Pressure 12. Timing Advance 13. Intake Air Temperature 14. Air Flow Rate 15. Absolute Throttle Position 16. Oxygen sensor voltages / associated short term fuel trims 17. Fuel System status 18. Fuel PressureSpecifications1. Software version: V2.1 (depending on software) 2. Hardware version: V1.5 3. Works with all OBD-II compliant vehicles 4. Support Four operating platforms (IOS, Android, Symbian, Windows) 5. SSID: WiFi_OBDII 6. IP: 192.168.0.10 7. Port: 35000 8. Communication: WIFI 9. Master chip: ST 10. Working voltage: 9~16V 11. Working current: 65mA 12. Standby current: 45mA 13. Operating temperature: -40~85 degree Celsius 14. Working Humidity: less than 60% 15. Size: 45mm x 25mm x 75mm 16. Compatible systems: Windows XP, Windows 7/8, IOS, Android, Symbian. 17. Supported protocols: - SAE J1850 PWM (41.6Kbaud) - SAE J1850 VPW (10.4Kbaud) - ISO9141-2 (5 baud init, 10.4 Kbaud) - ISO14230-4 KWP (5 baud init, 10.4 Kbaud) - ISO14230-4 KWP (fast init, 10.4 Kbaud) - ISO15765-4 CAN (11bit ID, 500 Kbaud) - ISO15765-4 CAN (29bit ID, 500 Kbaud) - ISO15765-4 CAN (11bit ID, 250 Kbaud) - ISO15765-4 CAN (29bit ID, 250 Kbaud)
